SKU: ELT2-MB7389
Elsys ELT-2 is an extremely versatile and robust LoRaWAN® sensor which is perfect for outdoor use with its IP67 rated casing.
Details Additional Info Data Sheet Manual£366.73*
Elsys ELT-2 is an extremely versatile and robust LoRaWAN® sensor which is perfect for outdoor use with its IP67 rated casing. This sensor is equipped with internal temperature, humidity, accelerometer and atmoshperic pressure nodes as standard. With the ability to be connected to a further two external sensors, the ELT-2 can measure and monitor a plethora of parameters such as soil moisture, external temperature, pulse counting, water leaks and distance to name but a few. Available with either an internal or separate external antenna, the ELT-2 can measure both analogue and digital inputs.
| Wireless Technology | LoRaWAN® 1.0.3 |
| Wireless Security | LoRaWAN® End-to-End encryption (AES-CTR), Data Integrity Protection (AES-CMAC) |
| LoRaWAN Device Type | Class A/C (configurable) End-device |
| Supported LoRaWAN Features | OTAA, ABP, ADR, Adaptive Channel Setup |
| Link Budget | 137 dB (SF7) to 151dB (SF12) |
| Available Frequency | EU868 (others available on request) |
| RF Transmit Power | 14 dB / 20 dB (Region specific) |
| Weight | 60 g excluding batteries / 100 g including batteries |
| Dimensions | 94 x 59 x 35 mm |
| Enclosure | IP67 |
| Operating Temperature | –40 to 60 °C (85 °C with external power supply) |
| Operating Humidity | 0 to 100% RH |
| Battery Type | 1 x 3.6V AA Lithium Battery |
| Expected Battery Life | <10 years (Depending on configurations and environment) |
Discounted Trade Pricing: Contact us for trade pricing, to place an order or to discuss your IoT projects.
All of our products are available to customers throughout Europe. For more information on shipping costs, currency conversions and lead times, please contact our technical sales team. Our technical sales team are also happy to advise customers on the best LoRaWAN® sensors to suit specific project requirements.
Certifications
