SKU: R311G
Netvox’s indoor LoRaWAN light sensor is used for the detection of ambient light intensity.
Details Additional Info Data Sheet Manual
Netvox's indoor LoRaWAN® light sensor is used for the detection of ambient light intensity. It can work in conjunction with other devices to perform wireless dimming functions in addition to helping reduce energy bills by remotely monitoring light levels in both occupied and unoccupied areas such as office spaces, homes and industrial sites. The wireless data signals are sent via LoRaWAN® protocol at pre-arranged intervals. Due to the compact and discreet design, the R311 range of sensors can be easily and quickly retrofitted to monitor conditions in workspaces, homes, hospitals and any other smart buildings. Alliot can pre-configure your chosen devices to work straight out of the box reducing the need for obtrusive and time consuming installations.
We can supply third-party online wireless sensor monitoring and notification system to view data and set alerts via SMS text and email. Ask us about our zero-touch provisioning service, this sensor can be supplied pre-configured and ready to go.
| Input Power | 2 x 3.0V CR2450 Button Batteries |
| Operating Power | DC 2.4V～3.0V |
| Standby Current | 12uA/3.0V |
| Transmitting Current (Max) | 120mA/3.0V |
| Receiving Current (Max) | 11mA/3.0V |
| Brightness Detecting Range | 1～3000LUX |
| Low Voltage Threshold | 2.4V |
| Voltage Measurement Accuracy | ±0.1V |
| Main Body Dimension | 57mm x 35mm x 15mm |
| Weight | 32.3g |
| Operating Temperature | -20°C ～ 55°C |
| Environment Humidity Range | <90% RH (No Condensation) |
| Storage Temperature | -40°C ～ 85°C |
All of our products are available to customers throughout Europe. For more information on shipping costs, currency conversions and lead times, please contact our technical team. Our technical team are also happy to advise customers on the best LoRaWAN® light sensors for their specific applications on an individual project basis.
